PR255

BDS Suspension adds to its extensive lineup of radius arm kits, 4-link and coilover options for the late model Ford Super Duty with new 2.5" coilover conversion systems bringing a new level of performance with minimal lift. These new systems convert the standard front coil springs over to FOX 2.5 remote reservoir coilovers for improved ride quality and performance across any terrain. The new coilover mounts key off the factory coil buckets for easy installation and allow the use of an auxiliary FOX 2.0 shock. Also included is your choice of alignment cams or BDS's heavy duty replacement radius arms. The arms are a bolt in replacement to the factory stamped steel arms and pair with an adjustable track bar to properly recenter the front axle. These systems allow for 35" tires to be installed. Get more out of your Ford Super Duty with BDS Suspension and FOX.

Factory Protection Plus
  • 5-year, 60,000 mile drivetrain Warranty
  • BDS’s exclusive No Fine Print Warranty

Product Description

2.5" Coilover Conversion Radius Arm Kit
2.5" Coilover Conversion Kit
2.5" Coilover Upgrade Kit

2.5" C/O Kit Features

  • FOX 2.5 remote reservoir coilovers improve ride quality & performance
  • Heavy duty adjustable track bar
  • Heavy duty radius arms for improved strength & correct axle positioning
  • Levels stance, with room for 35" tires
  • Bolt-on design, no welding needed

Kit ID Number(s)

#1509F  (2.5" C/O Radius Arm System)
#1510F (2.5" C/O System)
#1516F (2.5" C/O Upgrade Kit)

MSRP

$3584.97  (#1509F)
$3104.15  (#1510F)
$1927.60  (1516F)

Vehicle Fitment

2011-2016 Ford F250 Super Duty 4WD
2011-2016 Ford F350 Super Duty 4WD
*Diesel engine equipped trucks only

Rec'd Wheel/Tire Specs

35x12.50 Tires on 17x9/18x9/20x9 Wheels (5" Backspacing)

Available Accessories

#55358 - Dual Stabilizer Mounting Kit
#85405 - NX2 Steering Stabilizer (2req'd)
#95415 - 9500 Steering Stabilizer (2req'd)
#98224019 - FOX 2.0 Stabilizer (2req'd)

#123408/123409 - RECOIL Traction Bar Kit for F250/F350 (short bed)
#123418/123409 - RECOIL Traction Bar Kit for F250/F350 (long bed)
*Other accessories available, see website

BDS Suspension is now offering several FOX coilover options for the Ford Super Duty including complete lift systems and coilover upgrade kits for current BDS coil spring equipped trucks for improved performance and offroad capability. These new 2.5" lift systems are engineered for smooth on road comfort and unmatched performance out on the trail. These systems are designed with minimal lift and maximum performance, perfect for the Super Duty owner looking for more out of his tow rig on and off-road. As with all BDS lift kits these new coilover systems are backed by Factory Protection Plus offering BDS's no fine print warranty and a 5-year, 60,000-mile drivetrain protection. See more at 560plus.com. New 2.5" coilover systems include:

BDS 2.5" Coilover Conversion Radius Arm Systems - Take your late model Ford Super Duty to the next level of performance with minimal lift with the BDS 2.5" coilover conversion radius arm system. These systems convert the standard front coil springs over to FOX 2.5 remote reservoir coilovers for vastly improved dampening capability and performance across any terrain. This kit includes new coilover brackets that bolt into the factory coil buckets for easy installation and with provisions to secure the remote reservoir as well as an auxiliary FOX 2.0 shock in the stock shock location. Heavy duty replacement radius arms are also included in these kits. In place of the factory stamped steel arms this kit upgrades to heavy duty BDS radius arms built from 1-3/4" OD heavy wall tubing with gussets. These arms bolt right in place of the stock arms and for improved strength while correcting axle position. These paired with the heavy adjustable track to recenter the front axle and brake line relocation brackets finish up the front. In the rear, this kit uses a 4" replacement lift block to net a level stance  with room for 35" tires. Up the ante for improved performance from your late model Super Duty with BDS Suspension and FOX.

BDS 2.5" Coilover Conversion Systems - Get next level performance from your Ford Super Duty with the BDS 2.5" coilover conversion system without adding a ton of lift. These new systems convert the standard front coil springs over to FOX 2.5 remote reservoir coilovers for vastly improved dampening capability and performance across any terrain. The kit includes new coilover mounts bolt into the factory coil buckets for easy installation and allow the addition of an auxiliary FOX 2.0 shock in the stock location. Upper ball joint alignment cams are used to correct the positioning of the factory radius arms and paired with the heavy adjustable track to reposition the front axle under the truck.  Along with sway bar relocation brackets and brake line brackets, this kit uses a 4" replacement lift block and u-bolt kit to net a level stance with room for 35" tires. Take your Super Duty to the next level with BDS Suspension and FOX.

BDS 2.5" Coilover Upgrade Kit - These upgrade kits are designed for Super Duty owners currently equipped with the BDS 2.5" coil sprung lift systems #1509H/#1510H and will work with other kits in the 2-3" range. The 2.5" coilover upgrade kit will take your Super Duty to the next level with improved handling and shock performance over high speed offroad terrain while still offering smooth on road comfort. The kit utilizes a pair of specially tuned FOX 2.5 factory series remote reservoir coilovers designed for the weight of the Powerstroke diesel Super Duty. These coilovers come prebuilt for 2.5" of lift and are ready to go right out of the box. They use a smooth bore and honed seamless alloy body, 7/8" hardened steel carbon shaft, Eibach coil springs, 6061-T6 billet aluminum ends and specially formulated race proven oil. The threaded body is easily adjustable to dial in ride height to compensate for accessories like heavy winch bumpers. Also included are heavy duty upper and lower mounting brackets that bolt into the factory coil bucket and lower axle mount for easy installation with no welding required. The upper brackets integrates a mount to secure the remote reservoir. Upgrade you Super Duty with FOX 2.5 coilovers from BDS Suspension.

Ford Super Duty 2.5" Coilover Kit - Kit Photos

Click image to view and save high-res image.

#1509F 2.5" Ford Super Duty Coilover Radius Arm System
#1510F 2.5" Ford Super Duty Coilover Lift Kit
#1516F 2.5" Ford Super Duty Coilover Upgrade Kit

Ford Super Duty 2.5" Coilover Kit - Truck Photos

Click image to view and save high-res image.
