BDS 1624F Ram lift kit


New Product Release

PR #210

June 29, 2015




3″ Radius Arm System




2014-15 RAM 2500 4WD Diesel

*non air-suspension trucks only

Support Files & Links

View Installation Instructions

View lift online

Lift Kit
RAM 2500 3″ Radius Arm Kit – Shown with optional Fox 2.0 shocks
View High-Res Images: A, B, C, D

Dodge Ram w/ 3" BDS lift kit
RAM w/ BDS 3″ Radius Arm Kit
View High-Res Images: ABCD, E

BDS 3″ Radius Arm Systems for 2014+ RAM 2500 Trucks

Coldwater, MI — BDS Suspension adds to its stellar lineup of 2-6″ suspension lift options for the late model 2014-2015 RAM 2500 trucks with new 3″ radius arm systems designed to give you all the performance of a full-out lift system, but at a smaller height allowing the use of up to 35″ tires. The kits are tuned specifically for the new RAM 2500 trucks and offer premium ride quality and performance in any terrain while being backed by BDS’s unmatched No Fine Print Warranty. To continue reading about this kit see below, head online to the BDS website or check with your local BDS distributor.

BDS Suspension Systems are Protected by the Factory Protection Plus Program

Factory Protection Plus
  • 5-year, 60,000 mile drivetrain warranty
  • BDS’s exclusive No Fine Print Warranty

This new system is built around a pair of massive tubular replacement radius arms. These arms are built to handle the use and abuse RAM 2500 owners demand and far surpass the factory stamped steel arms with thick wall tubing and support gussets. They are formed inward to allow for addition tire clearance of oversized tires and incorporate factory style 3-1/4″ rubber bushings to minimize road vibrations while allowing for long, maintenance-free bushing life. The new radius arms mount right into the factory locations so installation is simple and clean. Factory alignment adjustability is maintained using the OE eccentric adjusters and the arms are designed to correct the geometry for 2-4″ inches of lift.

In addition to the heavy-duty, high-performance radius arms, this new system includes a pair of dual-rate front Pro-Ride coil springs to improve the ride and performance of these 3/4-ton trucks. A heavy-duty turnbuckle style adjustable track bar is included to recenter the axle. BDS greaseable front sway bar links reset the sway bar to the optimal operating angle. Rounding out this kit are brake line relocation brackets, 1.25″ tall rear coil spacers to level the stance and optimize the factory progressive rate coil springs and your choice of BDS 5500-series or Fox 2.0 performance gas shocks. Set your late model RAM 2500 up to perform in any terrain with BDS Suspension.

For more on this kit and available accessories for your Dodge Ram from BDS Suspension, log on to or call (517) 279-2135.
