PR213

NEW PRODUCT Anouncement

August 24, 2015

PR.213: 2016 Ford Super Duty Lift Kits

PART#

Diesel

#325H, #326H, #588H, #592H, #593H, #594H, #595H, #596H, #597H, #1500H, #1509H, #1510H, #596F, #597F, #596FDSC, #597FDSC

Gas

#325H, #326H, #578H, #580H, #582H, #583H, #584H, #585H, #586H, #587H,#1501H

PRODUCT

1″, 2″, 2.5″, 4″, 6″, 8″ Lift Kits

APPLICATION

2011-2016 Ford F250 4WD Diesel

2011-2016 Ford F350 4WD Diesel

MSRP

$251.92 – $5425.81

SUPPORT FILES & LINKS

View 2016 F250/F350 Kits Online

2 inch Coil Spacers
F250/F350 – 2″ Leveling Kits

2.5 inch Radius Arm System
F250/F350 – 2.5″ Radius Arm System

4-6 inch Standard Lift Kits
F250/F350 – 4-6″ Standard Lift Kits

4-6in 4-Link Systems
F250/F350 – 4-6″ 4-Link System

6in Coilover Conversion 4-Link System
F250/F350 – 6″ C/O 4-Link System

8 inch 4-Link System
F250/F350 – 8″ 4-Link System

1-8″ BDS Lift Kits for the 2016 Ford Super Duty

BDS Suspension now offers a full lineup of suspension lifts and accessories for the 2016 Ford Super Duty. All 2011-2015 Super Duty kits have been test fit and confirmed compatible with the new 2016 Ford F250/F350 Super Duty 4WD models. This lineup include 1-2″ leveling kits, radius arm kits, 4-8″ 4-link kits, Fox shock and coilovers, steering stabilizer kits and other accessories. All products are made to the highest standard and backed by Factory Protection Plus. All kits are designed to improve the trucks offroad performance and capability while maintaining on-road ride quality and handling. Take your 2016 Super Duty to new heights with BDS Suspension.

For more information on available kits see below, head online to BDS Suspension or call (517) 279-2135.

BDS SUSPENSION SYSTEMS ARE PROTECTED BY THE FACTORY PROTECTION PLUS PROGRAM

Factory Protection Plus
  • 5-year, 60,000 mile drivetrain warranty
  • BDS’s exclusive No Fine Print Warranty

2016 Ford Super Duty Lift Kits:

BDS Suspension is now shipping suspension lifts for the 2016 Ford F250/F350 Super Duty trucks. Available in 1″, 2″, 2.5″, 4″, 6″, and 8″ lift heights, these new kits are designed to improve the performance, functionality, and curb appeal of your late model Ford while retaining the handling characteristics owners have come to expect.

1-2″ Kits: The 1″ and 2″ leveling kits utilize a pair of lower coil spacers to retain the factory ride quality and handling characteristics while allowing for 33″ tires to be installed. 2″ kits include ball joint alignment cams. Your choice of BDS-5500 and Fox 2.0 performance gas shocks are available to upgrade the factory shocks. [see more]

2.5″ Radius Arm Kits: This small lift packs a big punch with clearance for up to 35″ tires. Kits include progressive rate Proride coil springs, a heavy duty adjustable track bar and thick-wall gusseted tubular radius arms to correct alignment caster and maximize ground clearance. In the rear a small replacement block is used to level the stance as well as your choice of BDS-5500 or Fox 2.0 gas shocks. [see more]

2.5-6″ Standard Kits: BDS offers 2.5″, 4″ and 6″ standard lift kits are available to clear up to 37″ tires. The 2.5″ kits include springs, blocks, your choice of shocks, sway bar relocation, alignment cams and adjustable track bar.  4″ and 6″ kits utilize a pair of 1/4″ thick drop brackets to reposition the stock radius arms for stock-like handling characteristics. A heavy duty track bar bracket recenters the front axle and mimics the new steering angles created by the forged pitman arm to eliminate bump steer issues seen with other kits. Also included is sway bar relocation, brake line extensions, bump stop extensions, new steering stabilizer mount, front and rear shocks, and your choice of rear block kit or replacement Glide-Ride leaf springs. [see more]

4-6″ 4-Link Kits: Stepping up from the standard 4″ and 6″ lift kits, BDS Suspension offers 4-link conversion kits to improve the handling characteristics and off-road performance. The 4-link design improves is much stronger while reducing caster change to less than 1 degree throughout wheel travel for better control. Heavy duty 4-link brackets with massive 2″ x .250 wall DOM tubular upper and lower greaseable control arms. These systems also integrate Pro-Ride coils, steering correction, sway bar relocation, brake line extension, your choice of available shocks and multiple rear lift options to level the stance. [see more]

6″ C/O 4-Link Kits: These C/O conversion kits take the performance to a new level with Fox 2.5 Factory Series remote reservoir coilover transforming the BDS 4-link system into a race prepped desert chase truck. The coilers are precision tuned to replace the factory coil-and-shock setup for vastly improved dampening offroad while still offering smooth on-road performance. The setup uses a replacement 1/4″ thick coilover mount with integrated auxiliary shock mount able to fit a 2.0-3.0 shock for increased dampening. This combined with BDS 4-link is an unbeatable under your Ford Super Duty. [see more]

8″ 4-Link Kits: Using the popular 4-link design, BDS offers the 8″ suspension lift kit able to clear 38″ tires and give you a new perspective on or off the road. The system includes longer upper and lower DOM tubular control arms, diesel/gas engine specific 8″ Pro-Ride coil springs, forged pitman arm, heavy duty track bar relocation bracket, bump stop extension, sway bar relocation, brake line extension, steering stabilizer mount, rear Glide-Ride leaf springs, and multiple front/rear shock mounting options. [see more]

Accessories: In addition to complete kits, BDS offers 4-link upgrade kits, dual shock mounting kits, an adjustable track bar, coilover upgrade kits, single or dual steering stabilizer kits, carrier bearing drop kits and more to outfit your 2016 Ford Super Duty. As with all BDS kits these are backed by the Factory Protection Plus Program. [see more]



© BDS Suspension, 491 W. Garfield Ave. Coldwater, MI 49036
(517) 279-2135 | bds-suspension.com | sales@bds-suspension.com
